Specification
Command:TSPL-EZ emmulation ,ZPL,EPL,DPL
Paper Width:20mm-80mm Paper
Diameter Paper roll:25-120mm
Reslution:203DPI
Length:1770mm(70inch Max)
Support 1D 2D bar code printing
Support Serial Sequence
Support Dlabel, Nicelabel, Bartender etc software
Feature
Resolution : 203 DPI
Print Method : Thermal Print
Print Speed(Max) : 127 mm (5″) / s,
Print Width(Max) : 76mm (3”)
Print Length(Max) : 1770mm(70″)
Printer Size : 225 mm (D) x151 mm (W) x151 mm (H)
Printer Weight : 1.08kg
Label Paper Roll Diameter : 25-120mm
Paper Direction : Paper Up
Processor : 32-bit CPU
Memory : 8M Flash memory
Interface : USB (Standard)
Power : Adaptor
– Input: AC 100-240V
– Output: DC 24V-2.5A
User Indicator : Standard Model
– 2 Press Buttons
– 1 LED Blue Light,1 LED Red Light
Sensor :
– Gap Sensor
– Cover Opening Sensor
– Printer Head Temperature Sensor
Paper Type : Thermal paper, Thermal adhesive paper, etc
Media Type : Continuous,Gap
Media Width : 20 mm ~ 82 mm
Media Thickness : 0.06 mm ~ 0.25 mm
Label Length : 10 mm ~ 1770 mm
BarCode :
1D bar code
Code128 subsets A.B.C,Code128UCC, EAN128, Interleave 2 of 5,Code 39,Code 93, EAN-13, EAN-8, Codabar, POSTNET, UPC-A, UPC-E, EAN and UPC 2(5) digits, MSI, PLESSEY, China Post, ITF14, EAN14, Code 11, TELPEN, PLANET, Code 49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
2D bar code
CODABLOCK F mode, DataMatrix, Maxicode, PDF-417, Aztec, MicroPDF417, QR code, RSS Barcode (GS1 Databar)
Rotation on font and Bar code : 0°, 90°, 180°, 270°
Command : TSPL-EZ emulation
Environment :
Operation Environment: -10 ~ 50 °C (14 ~ 122 °F), Humidity:10 ~ 90% No condensing
Storage Environment: -40 ~ 60 °C (-40 ~ 140 °F), Humidity:10 ~ 90% No condensing
Accessories :
– Windows Volume label editing software, driver and operation manual CD
– Fast installation guide
– Power adaptor
– Power cable
– USB cable
รับประกันสินค้า 1 ปี
