Print parameter
Printing Method : Thermal Line
Effective Printing Width : 48mm
Resolution : 384 dots/line(8dots/mm,203dpi)
Printing Speed : 70 mm/S
Interface :
USB (standard USB2.0 communication protocol, support Windows, Linux, Android, IOS)
USB+Bluetooth (Bluetooth2.0, Bluetooth3.0+4.0,support Android, IOS)
Line spacing : 3.75mm(Can adjust line spacing by command)
Line No :
Font A:32 character /Line
Font B:42 character/Line
Simple,traditional Chinese-16 lines
Character : The standard GB18030 simplified / traditional Chinese characters library
Character Size : ANK character,Font A:1.5×3.0mm(12×24 dots) Font B:1.1×2.1mm(9×17 dots) Simplified/Traditional:3.0×3.0mm(24×24dots)
Bar code character
Extended character set : PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/
PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/
(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)
Bar code :
1D.Bar code:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/CODABAR/CODE93/CODE128
2D.Bar code:QRCODE
Graphics printing
Graphics printing : Supports bitmap download and print
Power saving Mode
Smart power saving : Support
Variable speed printing : Support
Consumption : Support
Dormancy : Support
Detection
Sensor : Lack of paper detection
Indicator
Power Display : Support
Charge Indicator : Support
Lack of paper : Support
Paper
Type : Thermal
Width : 57.5±0.5mm
thickness : ≤0.12mm
Diameter : ≤40mm
Feed : Easy(Clamshell feed)
Print commands
Commands : ESC/POS
Power
Type : Rechargeable Lithium polymer battery
Capacity : 1500mAh/7.4V,
Charger : 5.0V/2A
Buffer
Input : 4KB
NV Flash : 40KB
Physical features
Weight : 200G
Dimension : 114*80*50(MM)
Environment
Operating : Temp:5 ~ 45℃, Humidity:10 ~ 80%
Storage : Temp:-10 ~ 50℃ ,Humidity:10 ~ 90%(No Dew)
Reliability
Print head life : 50KM(Printing Density≤12.5)
Software
Driver : Android,IOS,Linux,,WinXP,Win7,Win8,Win8.1,Win10
รับประกันสินค้า 1 ปี
